Articulating paper is one of the most used — and most overlooked — diagnostic tools in restorative dentistry. Choosing the right thickness, material, and marking technique directly affects occlusal accuracy, patient comfort, and restoration longevity. This guide covers everything Canadian dental professionals need to know about occlusal marking products available at EBIKO Dental.
As of May 2026, occlusal analysis remains a cornerstone of restorative and prosthetic workflows. Whether you are adjusting a new composite restoration, seating a crown, or equilibrating a full-arch case, the quality of your occlusal marks determines how efficiently you achieve balanced contacts. Yet many practices default to whichever articulating paper happens to be in the drawer, without considering how thickness, ink transfer, and substrate material affect diagnostic accuracy.
What Is Articulating Paper and Why Does Thickness Matter?
Articulating paper is a thin, ink-coated strip placed between the teeth to record occlusal contacts when the patient bites down. The ink transfers to high spots, guiding the clinician on where to adjust. The critical variable is thickness, measured in microns (µm).
- 200 µm (0.008″): The standard thickness for general occlusal marking. Produces clear, readable marks on enamel, composite, ceramic, and metal surfaces. Suitable for most restorative adjustments, crown seating, and denture checks.
- 100 µm and below: Thinner papers for fine occlusal analysis, particularly when adjusting implant-supported restorations or performing full-mouth equilibration where precision matters at the micron level.
- 40–60 µm: Ultra-thin films (often Mylar-based rather than paper) used for detecting premature contacts in sensitive prosthetic cases.
The general rule: thicker paper produces bolder marks that are easier to see, while thinner paper provides more precise contact information. Most general practices in Toronto and across the GTA will find that 200 µm paper handles 90% of clinical situations effectively.
Types of Occlusal Marking Products
Traditional Articulating Paper
Paper-based strips coated with ink on one or both sides. Available in blue, red, and green. Blue is the most common because it provides high contrast against tooth structure and most restorative materials. Red is useful as a secondary colour for differentiating centric from lateral contacts.
The Bausch Articulating Paper Strips Blue 200 Microns (0.008″) – 300/Box is the industry benchmark for reliable, consistent ink transfer. Bausch papers are manufactured in Germany with tight thickness tolerances, producing sharp marks without excessive bleed-through. At 300 strips per box, the per-strip cost is competitive for busy practices running multiple operatories.
For practices that prefer a domestic option with strong colour transfer, the Crosstex Articulating Paper – Blue delivers dependable performance for routine restorative work.
Articulating Paper Forceps
Holding articulating paper with cotton pliers works in a pinch, but dedicated forceps provide better control, consistent positioning, and faster workflow — especially when you need to check occlusion multiple times during an adjustment sequence.
EBIKO Dental carries Articulating Paper Forceps in two styles — straight and curved — designed to grip paper strips securely without slipping. The curved style is particularly useful for posterior placement where access is limited. The Miller Articulating Paper Forcep – Straight and Miller Articulating Paper Forcep – Curved are the most popular patterns among Ontario clinicians, offering a spring-loaded grip that holds the paper strip taut for clean contact registration.
Pro Tip: Dedicate one straight and one curved forcep per operatory. Having the right forcep within arm's reach eliminates the fumbling that slows down occlusal checks — a small investment that saves minutes per procedure across a full day of restorative work.
Clinical Technique: Getting Accurate Occlusal Marks
Even premium articulating paper produces misleading results if technique is off. Here are the fundamentals that separate reliable marks from artifacts:
1. Dry the Field
Saliva, blood, and bonding agent residue all interfere with ink transfer. Before placing the paper, dry the occlusal surface with a brief air blast. This single step dramatically improves mark clarity and reduces false positives from moisture-mediated ink smearing.
2. Guide the Bite
Ask the patient to close slowly into maximum intercuspation (MIP), not to "bite hard." Excessive force compresses the paper and produces oversized marks that obscure true contact points. For lateral excursion checks, guide the patient through smooth lateral and protrusive movements while the paper is in place.
3. Read the Marks Correctly
A common error is interpreting larger marks as higher contacts. In reality, a large ink spot may simply indicate a broad contact area, while a small but dense mark may represent the true premature contact. Look for marks with sharp, well-defined borders — these typically indicate true high spots. Diffuse, fuzzy marks often result from sliding contact or moisture contamination.
4. Use a Two-Colour Protocol for Complex Cases
For full-mouth equilibration or complex prosthetic adjustments, use blue paper for centric contacts and red for lateral excursions. This dual-colour approach lets you distinguish static from dynamic contacts at a glance, reducing adjustment time and improving accuracy.
Pro Tip: When adjusting ceramic or zirconia restorations, be aware that glazed surfaces resist ink transfer more than natural enamel. Use a slightly thicker paper (200 µm) and ensure the surface is completely dry. If marks are still faint, a light roughening of the glazed surface with a fine diamond bur before marking can improve ink adhesion.
Digital Occlusal Analysis: Does It Replace Articulating Paper?
T-Scan and similar digital occlusal analysis systems have gained traction in 2026, offering real-time force distribution data that paper cannot provide. However, digital systems come with significant cost — often $15,000 to $25,000 CAD for the hardware and sensors — and a learning curve that requires dedicated training.
For the majority of general practices in the GTA, articulating paper remains the practical, cost-effective standard. Digital analysis adds value in implant occlusion, TMD cases, and full-mouth rehabilitation where quantifying relative force distribution matters. But for everyday crown seats, composite adjustments, and denture equilibration, well-executed paper technique delivers reliable results at a fraction of the cost.
The pragmatic approach for Canadian practices: master paper technique first, then consider digital analysis as an adjunct for specific case types — not as a wholesale replacement.
Stocking Your Operatory: What to Order
A well-stocked restorative operatory should include:
- Blue articulating paper, 200 µm — your daily workhorse for centric contact checks
- Red articulating paper — for lateral excursion marking in complex cases
- Straight and curved Miller forceps — one of each per operatory for efficient paper placement
EBIKO Dental ships articulating paper and forceps across Canada with free shipping on orders over $99 CAD in the GTA, $199 CAD across Ontario, and $299 CAD nationwide. Our price match guarantee ensures you are getting competitive pricing on these everyday consumables.
Shop articulating paper, forceps, and restorative supplies at EBIKO Dental.
Frequently Asked Questions
Q: What thickness of articulating paper should I use for crown seating?
For routine crown seating, 200 µm (0.008″) blue articulating paper is the standard choice. It produces clear, visible marks on ceramic, zirconia, PFM, and gold surfaces. Thinner papers (below 100 µm) are reserved for fine occlusal analysis in implant or full-arch prosthetic cases where micron-level precision is required.
Q: How do I get articulating paper to mark properly on zirconia restorations?
Glazed zirconia resists ink transfer. Dry the surface thoroughly with compressed air before placing the paper. If marks are still faint, lightly roughen the glazed surface with a fine-grit diamond bur — this creates micro-texture that holds the ink. Use 200 µm paper for the boldest marks on resistant surfaces.
Q: Where can I buy Bausch articulating paper in Canada?
EBIKO Dental stocks Bausch Articulating Paper Strips Blue 200 Microns in 300-strip boxes, available for delivery across the GTA, Ontario, and all of Canada. Orders over $99 CAD ship free within the Greater Toronto Area. Visit ebiko.ca to order online.
